2200 Double Hung Window
Replacement
Our most popular replacement window!
The 2200 series double hung comes standard with features superior over the ordinary replacement window- including thermal performance, choice of top and bottom sash ventilation , easy clean feature, peace of mind locking system. Fabricated for today’s generation.
Standard ventilation latches and tilt-in sashes make it ideal for both single and multi-unit developments, and the ES U-4 Version 7 and E III Glazing Packages exceeds the highest standards.
Masterview’s double hung windows allow users to control ventilation flow with vertically sliding sashes that open from both the top and bottom.
The sashes can be opened in three configurations. Either the top or bottom can be fully opened while the opposite sash is closed, or both sashes can be opened halfway simultaneously. In all three positions, the double hung window provides a maximum opening of half the total window size. Each double hung window is equipped with a design feature that holds the open sash or sashes in place at any position.
Our double hung windows also have a tilt-in feature that allow for easy cleaning of the outside window from the inside of the building, making multi-story windows hassle-free to clean.
Standard
The unique design of the 2200 DH allows for maximum viewing area and light through a highly rigid slimline frame.
Energy Star U-4 and Energy Star III Glazing Packages exceeds the highest current Energy Star standards.
Our Energy Star U-4 and Energy Star III Glazing Packages can lower the average home energy bill by 30 to 40 percent, and cut CO2 output by 1,600 pounds per year*.
Energy Star III
- Duralite flexible, warm-edge spacers
Options
- Clear insulated glass (3/4″)
- Tints, Heat Reflection and other options available
* Courtesy Truseal Technologies
Standard
Options
Thermal Performance Data
| GLAZING | U-Factor | SHGC | VTT | CR |
|---|---|---|---|---|
| ES-4 Version 7 Double Strength Glass |
.26 | .49 | .60 | 48 |
| E III | .28 | .37 | .51 | 63 |
| Low E with Argon | .28 | .28 | .63 | 51 |
| High Performance Low E | .32 | .28 | .51 | 58 |
Standard
Options
The unique design of the 2200 DH allows for maximum viewing area and light through a highly rigid slimline frame.
Standard
Options
Standard
Options
Kasson & Keller, Inc. uses high grade alloyed cast steel in our hardware to ensure our windows stand the test of time.
| PRODUCT | MINIMUM TIP UP SIZE | MAXIMUM LIMITS |
|---|---|---|
| 2200 Double Hung | 17 X 26 | Dbl Locks 24 1/8″ TTT, maximum 47 5/8″ x 82 3/4 TTT, maximum UI 110 |
PLEASE NOTE:
Special Conditions and Design Requirements call for certain glazing components. Architectural specifications and wind loads should always be considered before ordering glazing products. These tooling limits are meant to serve as limits of production capabilities and will not warranty product performance of suitability to their end use. Many glass products that are offered as options are not in stock to fulfill all of the above sizes. Please consult customer Service for questions as to proper use.
Glass must be ordered from an outside source for units larger than 72” one way.
SPECIAL REQUIREMENTS?
Contact Us and We will see if we can Help!
Our Windows are made in the Northeast for the Northeast backed by 4 generations of our family – serving you since 1946.
MADE IN AMERICA
Best of Class Warranty
Our Windows are made in the Northeast for the Northeast backed by 4 generations of our family – serving you since 1946.
MADE IN AMERICA
Standard Exterior Colors
Black
Terrastone
Fieldstone
Autumn Red
Bronze
Hunter Green
Have a color in mind? We can custom match it!
*All representations of colors are mechanically reproduced and may vary from the actual product. Terms and conditions apply.
Whether You Are A Builder, Architect or Home Owner, Masterview Replacement Windows Will Offer You A Lifetime Of Worry-Free Operation, Backed By One Of The Best Warranties In The Industry.
* Rating, qualification, or compliancy is dependent on selected options and window style.
Contact Us
today and let us find the right replacement windows for your home.
ECOLOGY
• Low Energy Consumption
• Smaller Carbon Footprint
• Durable, Sustainable Materials
ECONOMY
• Lower Energy Bills
• Low Ownership Cost
• Best-of-Class Warranty
COMFORT
• Low Air Infiltration
• High-Tech UV Protection
• Outstanding Sound Reduction
2200 Bay
